Beovision 4002 and 4402 were colour receivers with 26″ screens. Natural colours, sharp, precise image definition and high-fidelity sound reproduction are all features you can take for granted, according to the 1970 – 80 Bang & Olufsen product catalogue. Their high reliability levels were due to modular construction techniques and low heat-generation. Beovision 4002 consumed only 110 watts – less than a black and white set of years previously.
Both sets were extremely easy to use. There were facilities for presetting up to eight stations so that subsequent programme selection was just a matter of pressing one button. This turned the set on at the same time.
Beovision 4402 had the additional convenience of a cordless (ultrasonic) remote control. The set could also be supplied equipped for Teletext reception. There was automatic synchronisation of VCR programmes on all channels.
Picture tube size: 66cm
Cabinet: wood veneer
Number of programmes: 8 VHF – UHF
Easy touch
Range: UHF 21 – 69, VHF 2 – 12
Start time: approx. 5 sec
Aerial impedance: 75 ohms coaxial
Speakers:
1 forward-facing pressure chamber
Sound power output: 6.5 W
Harmonic distortion: < 0.8 %
Frequency range: +/- 1.5 dB 60 – 15,000 Hz
Power bandwidth: 60 – 20,000 Hz
Bass control: +/- 5 dB / 100 Hz
Treble control: +/- 10 dB / 10,000 Hz
Power supply: 180 – 265 V
Power consumption: 110 W
Standby: 0 W
Dimensions W x H x D: 69.5 x 49 x 46cm
Weight: 36 kg
Undercarriages: Cross-base with castors 3043, Table with castors 3055
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
Beovision 4002 and 4402 were colour receivers with 26″ screens. Natural colours, sharp, precise image definition and high-fidelity sound reproduction are all features you can take for granted, according to the 1970 – 80 Bang & Olufsen product catalogue. Their high reliability levels were due to modular construction techniques and low heat-generation. Beovision 4002 consumed only 110 watts – less than a black and white set of years previously.
Both sets were extremely easy to use. There were facilities for presetting up to eight stations so that subsequent programme selection was just a matter of pressing one button. This turned the set on at the same time.
Beovision 4402 had the additional convenience of a cordless (ultrasonic) remote control. The set could also be supplied equipped for Teletext reception. There was automatic synchronisation of VCR programmes on all channels.
Please let us know
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
Beovision 3502 and 3802 – designed by David Lewis – were two 22″ colour TV receivers whose cabinets were of a moulded synthetic material. They were elegant and practical, according to B&O’s catalogue of 1979 – 80; the material was shock- and shatter-proof and fire-retardant. Dirty marks could be wiped off easily with a damp cloth.
Operation was easy and problem-free via the large, logically designed operation panels. Additionally in the 3802 model, all functions could be operated from a distance via the remote control module. Both receivers could accommodate a VCR without further technical adjustment. Beovision 3802 could also be equipped for Teletext reception. Automatic cut-off circuitry ensured the correct balance between colours without the need for regular adjustment by an engineer. High-bright picture tubes allowed for satisfactory viewing in daylight conditions. Modular chassis and low power consumption (and therefore less heat) ensured greater reliability.
Picture size: 56 cm
Cabinet: wood veneer
Start time: 5 sec
Automatic cut off
AFC
Number of programs 8 VHF – UHF
Easy touch
Ranges VHF 2 – 12, UHF 21 – 69
Speaker: forward-facing pressure chamber
Deflection angle: 110° in line
Aerial impedance: 75 ohms coaxial common VHF – UHF
Sound section:
Power output EMS: 1000 Hz 6.5 W
Distortion at specified output: < 0.8 %
Frequency response:
Amplifier +/- 1.5: dB: 60 – 15,000 Hz
Acoustical +/- 10 dB: 60 – 20,000 Hz
Bass control: +/- 5 dB / 100 Hz
Treble control: +/- 10 dB / 10,000 Hz
Power supply: 180 – 265 V
Power consumption 110 W
Stand by: 0 W
Dimensions W x H x D: 61 x 41 x 42cm
Weight 27 kg
Finishes: aubergine or white
Undercarriages: Trumpet stand 3054, Cross-base with castors 3043, Table with castors 3056
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
Beovision 3500 type number: 3907 was a 56cm colour television designed by David Lewis and Henning Moldenhawer. It could be placed on two types of stand – the trumpet stand (shown above) and the cross foot stand.
By 1975, colour television had become commonplace in homes throughout Western Europe. And a lot of those homes were furnished in white – the ‘in’ colour of the 1970s. Television, as a lot of home furnishings, followed this trend and Beovision 3500, with its trumpet base and cross-base on wheels, reflected what was happening in the world of interior design. The cabinet was made of moulded plastic and its appearance was markedly different from most other televisions of the era.
Beovision 3500 was Bang & Olufsen’s first fully transistorised television; this meant that very little warm up time was necessary for picture and sound. The choice of television channels had increased considerably over the previous years and the controls were adapted accordingly. “In everyday use, you select your TV programmes using the easy-touch push buttons at the top. Each of these can be set to one TV channel; this is done once only using the scaled potentiometer dials. These eight dials are only visible when the panel is opened; this is where you or your dealer can set the VHF and UHF channels that you are able to receive. Beovision 3500 has automatic frequency control, AFC, which locks the TV stations once they have been selected.” said the sales literature in 1975.
With Beovision 3500 it was clear that an icon had been created. The cabinet was made of moulded plastic and its appearance was markedly different from most other televisions of the time. However, the wooden cabinet was retained in the similarly-styled Beovision 3600 model. From 1975, Bang & Olufsen was also able to equip all its televisions with Automatic Cut-off Control.
An invention by the young engineer Erik Albert Jensen made waves internationally in the television sector. Cut-off Control ensures that the colour balance is maintained throughout the service life of the television. No fewer than 50 times each second the three electron beams are measured and corrected independently, thus avoiding any annoying deviations in colour.
(Taken from Beolink Magazine: ‘The First 50 Years of Television’ © Bang & Olufsen a/s 2002)
Plastic cabinet
Automatic cut off, AFC
Speaker: forward-facing pressure chamber
Deflection angle: 110°
Aerial impedance 75 ohms coaxial, common VHF-UHF
Power output RMS 1000 Hz: 6.5 W
Distortion at specified output: < 1 %
Frequency response:
Amplifier +/- 1.5 dB: 60 – 20,000 Hz
Acoustical +/- 10 dB: 60 – 20,000 Hz
Bass control +/- 5 dB: / 100 Hz
Treble control +/- 10 dB: / 10,000 Hz
Power supply: 220 – 240 V
Power consumption: 180 W
Dimension W x H x D: 61 x 41 x 42cm
Weight 29.5 kg
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
Beovision 3600 type number: 3908, 3909, 3938 was a 56cm colour television with a wooden surround.
Picture size: 56cm
Cabinet: wood veneer
Automatic cut off
Tuner: AFC
Speaker: forward-facing pressure chamber
Deflection angle: 110°
Aerial impedance: 75 ohms coaxial, common VHF-UHF
Power output RMS 1000 Hz: 6.5 W
Distortion at specified output: < 1 %
Frequency response:
Amplifier +/- 1.5 dB:60 – 20,000 Hz
Acoustical +/- 10 dB: 60 – 20,000 Hz
Bass control +/- 5 dB: / 100 Hz
Treble control +/- 10 dB: / 10,000 Hz
Power supply: 220 – 240 V
Power consumption 180 W
Dimension W x H x D: 61 x 41 x 42cm
Weight 29.5 kg
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
Like other Bang & Olufsen colour TVs, Beovision 3602 had the automatic cut-off regulating circuit which ensured natural colours throughout the set’s useful lifetime. The in-line picture tube allowed for easier and better convergence in order to avoid the usual discoloured edges – not least when viewing a black & white transmission.
Internally the Beovision 3602 was identical to the Beovision 3502 so one obtained the same outstanding picture quality and equally good sound reproduction from the large, forward-facing loudspeaker.
On the easy-touch panel one could select programmes and turn on the set in the same action. Regulators that are not used often are hidden in tow touch-release compartments – one for sound and one for video adjustments. Power consumption was exceedingly low – only 110 watts and the low heat generation made this set suitable for placing in a shelving unit.
Please let us know
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
Beovision 3702 was a 56cm colour TV with small outer dimensions, a highly advanced construction throughout and the most logical operation facilities then on the market.
The ultrasonic remote control was designed to be operated with one hand and its most important regulators could be ‘read’ by the finger tips. These regulators – for brightness, colour saturation and sound are set in relief, so there was no need to look. The user could feel which position was which by the tactile buttons.
Any of eight pre-set stations could be called, and, by pressing the special reset facility, all adjustment levels including sound, would revert to their predetermined basic levels.
Beovision 3702 could be switched off at the main ‘off button on the set’s simple operation panel. Or one could switch it off with the remote control module in which case, the set goes into stand-by position. By pressing one of the programme selectors there is a picture on-screen within 5 seconds together with sound. The picture tube was of the in-line type which needed fewer adjustments and consumed less power – only 115 watts.
The chassis was modular and there was an automatic cut-off regulating circuit to maintain long-term colour purity. Beovision 3702 could accommodate a VCR without further technical adjustment and could be fitted with a special optional kit to reproduce sound through a hi-fi system. Two pre-stamped blanks on the set’s fascia allowed for the insertion of a headphone or extension speaker terminal and switch.
Picture size: 56cm
Cabinet: wood veneer
Features: cordless remote control
Channel display: yes
Start time: 5 sec
Automatic cut off
AFC
Number of programmes: 16
Easy touch
Ranges 46 – 130 MHz, 131 – 300 MHz
Speaker: forward-facing pressure chamber
Deflection angle: 110° in line
Aerial impedance: 75 ohms coaxial
Sound section:
Power output EMS 1000 Hz: 6.5 W
Distortion at specified output: < 0.8 %
Frequency response:
Amplifier +/- 1.5 dB: 60 – 15,000 Hz
Acoustical +/- 10 dB: 60 – 20,000 Hz
Bass control +/- 5 dB: / 100 Hz
Treble control +/- 10 dB: / 10,000 Hz
Power supply: 180 – 265 V
Power consumption: 115 W
Stand by: 1.5 W
Dimensions W x H x D: 61 x 41 x 42cm
Weight: 28 kg
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
Beovision 3800 and 3900 were 22″ colour TV receivers finished in genuine wood veneers (teak or rosewood). They superceded models 3602 and 3702 in 1979. The sets were slim and elegant and their classic design suited any home décor according to the 1979 – 80 catalogue. High Bright picture tubes allowed for satisfactory daylight viewing since they permitted around 70% more light than from the screen than conventional picture tubes.
Beovision 3800 was for direct (set box) operation while Beovision 3900 permitted you to operate the set via an ultrasonic remote control handset. Beovision 3900 could also be supplied equipped for Teletext reception.
Automatic cut-off circuits guaranteed correct balance between the three basic colours (red, green blue) even after a long period of use. In fact, these sets incorporated every refinement which still makes Bang & Olufsen’s television sets among the market’s best. VCR programmes could be played without additional technical adjustment. There was an automatic synchronisation on all channels.
A choice of two mobile undercarriages were available. A tall undercarriage (42cm high, type 3057) depicted here, and a lower one (34cm, type 3058). Both were sold as optional accessories
Picture tube: 56cm (nominal) 20AX in-line High Bright
Start time: Approx 5 seconds
Tuning: 8 pre-sets with AFC; UHF channels 21-68
Aerial input: 75 ohms co-ax
Sound output: 6,5W RMS
Harmonic distortion: <0,8%
Frequency response: 60 – 15KHz +/- 1,5dB (amplifier)
Bass control: +/- 5dB/100Hz
Treble control: +/-10dB/10000Hz
Optional accessories:
Undercarriage – 34cm high: type 3058
Undercarriage – 42cm high: type 3057
Headphone/ext. speaker kit: 8003207
Tape/amplifier kit: 8003208
Dimensions (HxWxD): 43 x 67,5 x 40,5cm
Power supply: 180 – 265V AC 50Hz
Power consumption: 110W
Weight: 28 kg
Types:
3524 (1978 – March 1982)
16 CH 3523 (1978 – June 1980)
GB 3525 (1978 – June 1980)
Picture tube size: 56cm (nominal)
Cabinet: wood veneer
Automatic AFC
Automatic cut off
Number of programmes: 8 UHF
Range: UHF 21 – 69 (VHF 2 – 12)
Picture tube: 110° in line
Start time: approx. 5 sec
Aerial impedance: 75 ohms coaxial
Sound power output: 6.5 W
Harmonic distortion: < 0.8 %
Frequency range: +/- 1.5 dB 60 – 15,000 Hz
Bass control: +/- 5 dB / 100 Hz
Treble control: +/- 10 dB / 10000 Hz
Power supply: 180 – 265 V
Power consumption: 1150 W
Stand by: 1.5 W
Dimensions W x H x D: 67.5 x 43 x 40.5cm
Weight 29 kg
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
Beovision 3502 and 3802 – designed by David Lewis – were two 22″ colour TV receivers whose cabinets were of a moulded synthetic material. They were elegant and practical, according to B&O’s catalogue of 1979 – 80; the material was shock- and shatter-proof and fire-retardant. Dirty marks could be wiped off easily with a damp cloth.
Operation was easy and problem-free via the large, logically designed operation panels. Additionally in the 3802 model, all functions could be operated from a distance via the remote control module. Both receivers could accommodate a VCR without further technical adjustment. Beovision 3802 could also be equipped for Teletext reception. Automatic cut-off circuitry ensured the correct balance between colours without the need for regular adjustment by an engineer. High-bright picture tubes allowed for satisfactory viewing in daylight conditions. Modular chassis and low power consumption (and therefore less heat) ensured greater reliability.
Picture size: 56 cm
Cabinet: white plastic
Features: cordless remote control
Start time: 5 sec
Automatic cut off
AFC
Number of programs 8 VHF – UHF
Easy touch
Ranges VHF 2 – 12, UHF 21 – 69
Speaker: forward-facing pressure chamber
Deflection angle: 110° in line
Aerial impedance: 75 ohms coaxial
Sound section:
Power output EMS 1000 Hz 6.5 W
Distortion at specified output: < 0.8 %
Frequency response:
Amplifier: +/- 1.5 dB 60 – 15,000 Hz
Acoustical: +/- 10 dB 60 – 20,000 Hz
Bass control: +/- 5 dB / 100 Hz
Treble control: +/- 10 dB / 10,000 Hz
Power supply: 180 – 265 V
Power consumption: 115 W
Stand by 1.5 W
Dimensions W x H x D: 61 x 41 x 42cm
Weight 28 kg
Finishes: white
Undercarriages: Trumpet stand 3054, Cross-base with castors 3043, Table with castors 3056
