Beovision 11-46
Beovision 11-46
B&O’s first smart TV, being based on the design of the successful Beovision 10. Major changes include the 3D facility and an upgraded sound performance. 6 HDMI ports are available, one being on the accessory panel, and the TV can be controlled with either the Beo4 or 6 or via an iPad or Android tablet.
Beovision 11-46 Product Details
Type Numbers
Please let us know
Designer
Manufactured
2012 -
Colour Options
Frame/Cabinet: Black/black, silver/black, black/white, silver/white
Front cover: Black, blue, dark grey, red, silver, white
Beovision 11-46 Product Specification
CONTRAST SCREEN
Anti-reflection coating on both sides
ENVIRONMENTAL
POWER CONSUMPTION
11-40:
230V Typical (IEC 62087:2. ed): 123 W/Standby: 0.4 W
110V Typical: 106 W/Standby: 0.3 W
11-46:
230V Typical (IEC 62087:2. ed): 136 W/Standby: 0.4 W
110V Typical: 133 W/Standby: 0.3 W
11-55:
230V Typical (IEC 62087:2. ed): 154 W/Standby: 0.4 W
110V Typical: 150 W/Standby: 0.3 W
PEAK LUMINANCE RATIO
65%
ENERGY EFFICIENCY CLASS (EU)
11-40: C
11-46: C
11-55: B
MAINS VOLTAGE RANGE
100-240 VAC, 47-63 Hz
OPERATING CONDITIONS
10-40° C, 50-104° F
Humidity: 30%-70%
TV PLATFORM
CHASSIS
Video Engine 1.5
THEFT PROTECTION FEATURE
Pin code
PICTURE FORMATS
Automatic format handling incl. Black Bar Detection
Automatic modes: AUTO, AUTO WIDE
Manual override modes: FIXED FORMAT A, B, C* and D*
(*Incl. vertical scroll)
HDMI INPUT FORMATS
2D formats:
480i, 480p, 576i, 576p, 720p, 1080i, 1080p,
640×480, 800×600, 1024×768
3D formats:
1080p Frame Packing/Top-and-Bottom
720p Frame Packing/Top-and-Bottom
1080i Side-by-Side (Half)
FURTHER INFO ON PICTURE INPUT FORMATS
See PDF: Vision Clear formats
DIGITAL SURROUND SOUND MODULE
Standard built-in
SOUND INPUT FORMATS
PCM, multichannel PCM
DIGITAL SOUND DECODING CAPABILITIES
Multichannel PCM, Dolby Digital, Dolby Digital Plus 7.1, DTS Digital Surround, HE-AAC v1 and v2, LC-AAC, mp3, WMA, WMA lossless, FLAC
Up- & down-mixing: B&O True Image, downmix, 1:1
DISPLAY
SCREEN TYPE
11-40 16:9 TFT LCD, glare surface
BACKLIGHT TYPE
Edge-type LED
1.5D local backlight dimming
RESOLUTION
1920 x 1080 pixels (Full HD)
3D FUNCTION
Active shutter glasses required
REFRESH RATE
200 Hz/240 Hz
LUMINANCE OF WHITE (CENTRE OF SCREEN)
Typical 450 cd/m2
CONTRAST RATIO (CENTRE OF SCREEN)
Typical 5000:1
RESPONSE TIME (GREY TO GREY)
Typical 6 msec
PICTURE OPTIMISATION
VisionClear
ROOM ADAPTATION
Automatic Picture Control
360 degree light measurement
COLOUR CALIBRATION
10-point display calibration
CONTRAST ENHANCEMENT
Adaptive contrast algorithm
1.5D local backlight dimming
MOTION PICTURE IMPROVEMENT
Adaptive film judder compensation
ANALOGUE TUNER
US: Not available
VIDEO TYPE / FORMAT
Analogue:
According to type and setup:
B/G/L/L’/I/D/K/M
FREQUENCY RANGE
45-863 MHz
ANALOGUE STEREO DECODING CAPABILITIES
A2 + Nicam
AERIAL INPUT CONNECTION(S)
1 x F-connector for analogue and digital input
DIGITAL TUNER
T2/C, T2/C/S2 or Dual T2/C/S2 HDD
Optional (T2/C standard)
US: Not available
VIDEO TYPE/FORMAT
DVB-T/T2, DVB C, MPEG2/4 HD
MPEG2: MP@ML, MP@HL
H264: MPEG4 AVC, main and high profile level 4
AUDIO TYPE/FORMAT
MPEG1:
2-channel audio decoder, layer 1 and 2.
MPEG2:
2-channel audio decoder, layer 2
AAC, AAC+ Dolby Digital, Dolby Digital Plus
FREQUENCY, RANGE AND IF BANDWIDTH
Terrestrial T/T2:
104-862 MHz (Band 3, 4, 5)
IF Bandwidth 6, 7 and 8 MHz, selectable
Auto tuning 174-230 MHz and 470-858 MHz
Cable:
48-862 MHz (Band 3, 4, 5)
IF Bandwidth 6, 7 and 8 MHz, selectable
Auto tuning 110-858 MHz
Satellite S/S2(optional):
10700-12750 MHz,
IF Bandwidth 950-2150 MHz
Auto tuning 174-230 MHz and 470-858 MHz
COFDM (ORTOGONAL FREQ. DIVISION MODULATION) SPECTRUM
2K and 8K, non-hierarchical
MODULATION
Terrestrial T/T2:
QPSK, 16QAM, 64QAM
Cable:
16, 64, 128, 256 QAM
Satellite S/S2:
8PSK, QPSK
CODE RATE
Terrestrial T/T2 :1/2, 2/3, 3/4, 5/6, 7/8, 3/5, 4/5
GUARD INTERVAL
Terrestrial T/T2 :1/32, 1/16, 1/8, 1/4, 1/128, 19/256, 19/128
SYMBOL RATE
Terrestrial T/T2: 2-45 Msymb/sec
Cable: 4-7 Msymb/sec
Satellite S/S2: 1-45 Msymb/sec
AERIAL INPUTS CONNECTION
1 x F-connector for DVB-T2/C and analogue
Active antenna supply 5V/50 mA
1 x F-connector for DVB-S/S2 (optional)
ODU CONTROL
DiSEqC level 1.1 (digital satellite equipment control)
DC for switching between H/V polarizations
13.5 V +/- 5% max 450 mA
18.5 V +/- 5% max 450 mA
Tone Control for low or high band selection
22 kHz/0.65 Vpp +/- 0.25 V duty cycle 50% +/- 10%
Cable length compensation selectable +1 V LNB supply boost
COMMON INTERFACE AND SMART CARD SLOTS
Common interface according to EN50221
CI and CI+
2 x PCMCIA (Common interface only)
All CA systems available as common interface is supported
CA power supply: max 5 V/500 mA
INSTANT RECORD
Yes (One button function)
TIMER RECORD FUNCTION
Yes
REPLAY FUNCTION
Yes
TIME SHIFTING
Yes (Pause TV)
HARD DISK RECORDING CAPACITY
Yes (Pause live TV with 4 hour time shift buffer)
Up to 500 hours for SD and up to 300 hours for HD (500 Gb)
SOUND
LOUDSPEAKER
Integrated three way stereo speaker
(centre speaker if surround sound setup)
POWER AMPLIFIERS
6x Class D ICEpower
POWER PER AMPLIFIER
32 W
EFFECTIVE FREQUENCY RANGE
11-40 44 Hz – 22.8 kHz
11-46 44 Hz – 22.9 kHz
11-55 45 Hz – 23.0 kHz
CROSSOVER FREQUENCY RANGE
11-40 300 Hz and 4 kHz
CABINET PRINCIPLE
11-40 and 11-46:
WOOFER: Closed box
MIDRANGE: Closed box
TWEETER:-
11-55:
WOOFER: Bass reflex
MIDRANGE: Closed box
TWEETER:-
WOOFER 4″
MIDRANGE 2″
TWEETER 3/4″
CABINET VOLUME
40: 0.8 liters
46: 2.1 liters
55: 2.5 liters
BASS EQUALISER
Adaptive Bass Linearisation (ABL)
PROTECTION
Thermal protection
CONNECTIONS
IR CONTROL OUTPUTS (PUC)
6 x (3 x RJ45, two outputs in each)
ANALOGUE VIDEO CONNECTIONS
1 x mini AV input (RGB FB or CVBS and one way AVL)
PAL, SECAM, NTSC
USB
2 x USB connector
5V DC/500 mA
USB HDD, USB key
Media player (HomeMedia): Picture, music, movies
Software: Software update, Peripheral Unit Controller (PUC) table download
ETHERNET
1 x Ethernet RJ45 10/100 Mbit/s
Functions:
Media player (HomeMedia) allowing playback of picture, music and movies from NAS via UPnP, HBBtv, software update, PUC table download allowing you to control a set-top box with the Bang & Olufsen remote control
DIGITAL VIDEO CONNECTIONS
6 x HDMI free configurable (one HDMI-in located at the easy access)
DIGITAL SOUND CONNECTIONS
1 x RCA SPDIF, free configurable
LOUDSPEAKER OUTPUTS
5 x RJ45 Power Link, allowing up to 10 BeoLab speakers
STEREO HEADPHONES
1 x mini-jack
MOTORISED STAND CONNECTION
1 x micro fit 4 pin
FEATURES
BEOLINK
Network Link
NETWORK LINK OPTIONS
V.OPT 1, 2 and 4
AUDIO DISTRIBUTION
Requires BeoLink Converter NL/ML to Master Link products
PERIPHERAL UNIT CONTROLLER
Integrated Peripheral Unit/Set-top Box
Controller:
Controlling 6 units
HBBtv
Available
Bang & Olufsen Smart TV
Available
SPLIT SCREEN
Picture-and-Picture (PAP)
Teletext-and-Picture (TAP)
TELETEXT
Teletext level 1.5, 4000 pages
9 memory pages per channel
SOUND MODES
9 editable sound modes
SPEAKER GROUPS
9 user-configurable speaker groups
WLAN
IEEE 802.11a/n/b/g, WOW, WOL, MIMO 2×3
2.4 GHz
5 GHz
Controllable via iPad
Requires iPad
Controllable via Android tablet
Requires Android tablet
Support for HDMI Matrix
Yes, 4×4, 4×8, 8×8, 16×16
MENU LANGUAGE(S)
Chinese Simplified, Chinese Traditional, Danish, Dutch, English, French, Finnish, German, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Romanian, Russian, Spanish, Swedish
MEDIA PLAYER
MEDIA
USB device or DLNA
MEDIA PLAYER DECODING CAPABILITIES
See PDF Supported formats
MEDIA CONTAINERS
MKV, MP4, ASF,AVI, MP2TS, MP2PS, MOV,VIDEO CODECS
MP1V, MP2V, MP4-ASP, H264, MJPEG,VC-1, WMV9, XviD
PHOTO FORMATS
jpg, .bmp, .tiff, png, .gif
MEDIA PLAYER
Available
DLNA
Available
ONLINE SW UPDATE
Available
PLACEMENT OPTIONS
Motorised floor stand, motorised wall bracket, wall bracket, easel stand (black, white), cable cover
REMOTE CONTROL
Beo4, remote control via iPad or Android tablet or Beo6 – optional
