BeoSound Shape
BeoSound Shape
Define and redefine your perfect shape
Beosound Shape is a uniquely flexible speaker system that can grow and evolve with the changing ways you live. Rearrange the tiles to form a new pattern, change the colours when you redecorate or add more tiles to boost sound performance or acoustic damping properties.
All sound. Enjoy silence. Celebrate originality.
Beosound Shape is a modular speaker system for design conscious music lovers. Hanging like a unique piece of art, it delivers immersive sound staging and the ability to improve your room acoustics with its built-in noise dampers.
Create your own design
No two configurations are likely to be the same, and that’s the whole beauty. Yet each one will undoubtedly leave a lasting visual imprint – on every wall and every room.
Try our configuration tool to create your personal Beosound Shape design. Start by defining the pattern and look. Complete your design by choosing a performance level that matches your needs.
Expand your experience
Beosound Shape is a part of our ever-growing home speaker collection. The products seamlessly connect into one Multiroom audio system with the potential to expand to every room of your home.
A band on your wall
Prepare for an innovative and social music experience that brings ‘the band’ right into your room. Beosound Shape cleverly utilises a setup with multiple speakers to deliver a concert-like perception of singer and instruments. Book a demo, to feel the sensation.
Turn down the noise
Poor indoor acoustics makes even the most beautiful room unpleasant to be in. Relieve the problem by integrating acoustic damper tiles when you design your Beosound Shape.
The heart of your music
At the heart of the system lies our Beoconnect Core connectivity hub. A small built-in box that lets you stream music directly from your phone or tablet via Google Cast, Apple AirPlay and Bluetooth.
All-in-one speaker system
Beosound Shape is more than just a wireless speaker. It is a complete audio system that can boast as many as 40 individual speakers, playing your digital music in rich and high-res audio quality.
BeoSound Shape Product Details
Type Numbers
Please let us know
Designer
Manufactured
Please let us know
Colour Options
Please let us know
BeoSound Shape Product Specification
Recommended Room Size
20-100 m²
Speaker Configuration
Per Speaker Tile:
1 x ¾” tweeter
1 x 5 ¼” woofer
Amplifier
Per Amplifier:
8 x 80 Watt class D
Maximum speakers per amplifier: 4
Frequency Range
30 – 22.000 Hz (8 tiles set up)
Maximum Sound Pressure Level (SPL) @1m
105 dB (8 tiles set up)
Bass Capability
89dB (SPL) (8 tiles set up)
Advanced Sound Features
Adaptive Bass Linearization
Thermal Protection
Materials
Textile
Polymer
Dimensions
36.4 W x 32.0 H x 11.1 D cm (1 Tile)
Maximum Amplifier Tiles: 11
Maximum Speaker Tiles: 44
Acoustic Damper Tiles: unlimited
Weight
Speaker Tile: 1.9 kg + 0.4 kg (fabric cover)
Amplifier Tile: 2.0 kg + 0.4 kg (fabric cover)
Damper Tile :0.51 kg + 0.4 kg (fabric cover)
Power supply
100-240V 50/60Hz mains cable
Bluetooth version
Bluetooth 5.3
Bluetooth Codecs
Android: SBC
iOS: SBC, AAC
Wi-Fi
Dual-Band Wi-Fi (2.4 & 5 GHz)
IEEE 802.11 b/g/a/n/ac/ax
Streaming Services
Apple AirPlay
Spotify Connect
Google Cast
TIDAL Connect
B&O Radio
Deezer
QPlay 2.0
Beolink Multiroom
Yes
Physical Connections
Speaker Tile:
1 x Speaker 4-Wire Input
Amplifier Tile:
4 x Speaker 4-Wire Output
1 x Optical-In
1 x Power Link (RJ45)
1 x Comm In (Amplifier Input)
1 x Comm Out (Amplifier Output)
1 x USB-B
1 x Power
Beoconnect Core:
1 x Power
1 x USB-C (Digital Performance Output)
1 x HDMI eARC (for TV-integration)
1 x Ethernet
1 x COMM (for Beosound Shape)
1 x Powerlink (Stereo)
1 x Line-In
Remote Controls
Bang & Olufsen App
Beoremote One BT
Beoremote Halo
Gold or Silver membership required to view documents
Available documents are listed, if none are listed then please reach out to see if we have them.
Type | Language | Type | |
Data Sheet | EN | BeoSound Shape Data Sheet |
BeoSound Shape FAQs
Please let us know
