CTV system: Multi-standard B/G/L (GB: PAL I)
Colour system: PAL/SECAM, NTSC A/V 4.43 MHz / 3.58 MHz
Picture tube (Visual picture): 63cm (59cm)
Picture tube system: flat square, Hi-Bri, In-Line 110 degrees
Contrast screen with metallised coating
Design: wide format cabinet
Cabinet: rosewood, grey metallic

Main features:
Operation Beolink 1000, one-way (prepared for two-way)
Sound centre balance: between BeoLab and Beovision speakers

Sound system: Built-in NICAM EU + A2 stereo decoder
Built-in NICAM EU + A2 dual language
TV tuner range: 46 – 855 MHz: VHF, S, Hyper, UHF
No. of TV programmes: 50
Satellite: prepared for BeoSat LM kit
No. of satellite programmes: 64
Signal/noise level: > 35 dB/1 Vpp and antenna signal > 1mV
Crosstalk between sources: > 45 dB / 5 MHz
Teletext FLOF, TOP, 5 alphabet, 6 alphabet (E)
Teletext memory 4 x 50 page nos
Station identification Via Teletext/station naming
Speaker system: 2 x bass reflex
Speaker units: woofer 2 x 7.5 cm, tweeter 2 x 5 cm
Crossover frequency: 2500 Hz
Long-term max. output power: 2 x 40 W / 8 ohms
Harmonic distortion: < 0.5% at 15 W
Intermodulation: < 1%
Signal-to-noise ratio: > 50 dB weighted 50 mV (NICAM > 70 dB)
Frequency range, audio: 25 – 20,000 Hz +/- 1.5 dB
Power bandwidth: 25 – 20000 Hz
Bass control: +/- 8 dB / 100 Hz
Treble control: +/- 8 dB /10000 Hz

Power supply: 220 – 240 V
Power consumption: 100 (75 – 165) W
Power consumption stand-by: 3 W
Dimensions W x H x D: 77.5 x 47.5 x 42.5cm
Weight: 32.6 kg

Connections: AV Link 2 x 21-pin SCART
Super VHS YC playback 4-pin socket
Audio Aux Link 7-pin socket
Power Link 2 x 8-pin sockets
External speakers 2 x 2-pin sockets
Motorized stand operation 4-pin socket
Aerial VHF – UHF 75 ohms coaxial socket
Stereo headphones: jack socket 6 mm
Link compatibility: Datalink
