BeoLink Converter

BeoLink Converter

This product allows the use of audio and video products with Audio Aux (Datalink) in aย MLย system. It has a clever auto configuration feature which means it sets itself up depending on the connected units. Uses can be to connect an older audio set up such as a Beomaster 7000ย to a newer video set up such […]

Overview

This product allows the use of audio and video products with Audio Aux (Datalink) in aย MLย system.

It has a clever auto configuration feature which means it sets itself up depending on the connected units. Uses can be to connect an older audio set up such as a Beomaster 7000ย to a newer video set up such as anย Avantย or a newer audio set up to an older TV.

It has a supplementary use in that it could be used with aย Beocenter 2300/2500ย which were fitted withย MCLย drivers to power anย MLย system. This requires the Converter to be of the newer type : 1161166. the older 1161466 is unable to perform this function.

Product Details

Type Number:1611, 1612, 1614
Release Date:1995
Designer:David Lewis
Colour / Finish:Black

Product Specification

For connection between ML and AAL audio and video products.
Link room product
Operation
Remote operation Beolink 1000 one-way
(Through connected products) Beo4 one-way
Beolink 5000 two-wy (only AV 9000 Audio kit)
Compatibility Beosystem AV 9000
All A/V masters with Master Link distribution
All video masters with Master Link distribution
Cabinet Black aluminium/plastic
Placement Fastened to the wall

System data
Frequency response 20 - 20,000 Hz +0/-1 dB
Signal-to-noise ratio > 82 dB
Dimensions W x H x D 20 x 10.5 x 4 cm
Power consumption, operation 2.1 watts (230 V AC)
Power consumption, stand-by < 1.5 watts (230 V AC)
Weight 0.6 kg

Downloads

    Type

Language

Type

    Type

Service Manual

EN

1611, 1612

BeoLink Converter Service Manual

Service Manual

EN

1614

BeoLink Converter Service Manual
