An update to the cheapest of the column speakers, this saw the Class AB amplification discarded along with the large heat sinks. Instead 2 cool running ICE amplifiers were fitted, both rated at 125W.
The LED was repositioned and the finish of the foot changed to match the TV range. A three position switch for wall, corner and free position settings was now fitted and the previous model’s phono plug was deleted. 2 Powerlink sockets were still present though.
POWER CONSUMPTION
Typical: 19 W; Networked standby: 0.4 W
LONG-TERM MAXIMUM OUTPUT
POWER AMPLIFIER, BASS
125 W, Class D, ICEpower
POWER AMPLIFIER, TWEETER
125 W, Class D, ICEpower
EFFECTIVE FREQUENCY RANGE*
46-27,000 Hz
SENSITIVITY**
88 dB SPL re 125 mVrms re 1m
CABINET PRINCIPLE
Bass reflex
CABINET VOLUME
3 litres
BASS DRIVER
2 x 3½” cone
HIGH FREQUENCY DRIVER
¾” dome
FEATURES
Adaptive Bass Linearisation (ABL)
Room adaptation
Thermal protection
CONNECTIONS
2 x Power Link
Line in via Power Link
ACCESSORIES
Wall bracket, silver
Stand, black
Cover
ROOM ADAPTATION
Free, Wall or Corner position
MAGNETICALLY SHIELDED
No. Must be placed > 50 cm from picture tube
INPUT SENSITIVITY (POWER LINK)
125 mV (88dB SPL)
INPUT SENSITIVITY (LINE)
125 mV (88dB SPL) – Auto switch on
SWITCH-OFF TIME (LINE)
3 min.
INDICATOR
On/Off LED
OPERATION
Switch for Free, Wall, Corner
Switch for Left – Right – Line (via PL plug)
PROTECTION
Thermal protection of all drivers.
ABL system protects the bass unit against mechanical damage.
POWER SUPPLY
Automatic voltage adaptation 100-120Vac or 190-240Vac
MEASUREMENT CONDITIONS:
*EFFECTIVE FREQUENCY RANGE is measured at -10 dB re. Ref level (200-2000 Hz)
**SENSITIVITY is measured at dB SPL 1m re 125 mV
