BeoCord VX7000

BeoCord VX7000

Beocord VX7000 video cassette recorder was operated and programmed with the Beo4 remote control (although could equally, if not be better controlled, through the previous two-way Beolink 5000 remote control unit) through Beovision MX models. All channels stored on the TV were simultaneously stored on the VX7000. In 1995 a new model was released specifically designed to operate […]

Overview

Beocord VX7000 video cassette recorder was operated and programmed with the Beo4 remote control (although could equally, if not be better controlled, through the previous two-way Beolink 5000 remote control unit) through Beovision MX models.

All channels stored on the TV were simultaneously stored on the VX7000. In 1995 a new model was released specifically designed to operate through the Beo4 remote control unit and lost the two-way communication that had been one of its greatest selling points.

Features: hi-fi stereo VCR; NICAM/A2, PAL/NTSC converter; Beo4 remote control (1995 models onwards); black fascia; cabinet in the same colour schemes as the Beovision MX7000 plus black.

Product Details

Type Number:4587,4581,4580,4585,4589,4588,4586,4584,4583,4617,4614,4611,4613,4610,4615,4619,4618,4616
Release Date:1993, 1994, 1995, 1996, 1997
Designer:David Lewis

Product Specification

BeoCord VX7000 VHS VCR

Dimensions W x H x D/Weight 54 x 8.5 x 30 cm/8.5 kg
Cabinet finish White, Black
Terminal recommended via Beovision: Beolink 5000
Tuner range VHF, S, Hyper, UHF
UHF (4589)
CTV system B/G PAL
PAL I (4589)
B/C/PAL/SECAM (4585)
TV programmes 59
Stereo decoder NICAM + A2
Recording system HQ
Slow motion 1/7 normal speed
Still picture Noiseless
Tape counter Track, time left, time used

Timer programming
8, 1 year
Sound system Hi-Fi stereo
Video playing time, E-240 SP 4 hours, LP 8 hours
Audio playing time, E-240 LP 8 hours

Power consumption / Minimum
34 watts/10 watts

Cassette format
VHS

Picture functions:
Playback tapes recorded in NTSC 4.43 MHz or PAL 60 Hz
Fast forward and rewind Less than 5 min. E-240
Search forward SP 7 x and 15 x normal speed
Search backward SP 2 x and 7 x normal speed
Search forward LP 5 x and 13 x normal speed
Search backward SP 2 x and 5 x normal speed
Tape heads 5 video, 2 Hi-Fi audio

Connections: AV AV Link 21-pin socket
Camcorder IN 3 phono sockets
RF IN 75 ohms
RF OUT 75 ohms
Camera pause Jack 2.5 mm socket

Beocord VX7000 Beo4 (One-way)

Dimensions W x H x D/Weight 54 x 8.5 x 30 cm/8.5 kg
Cabinet finish White, Black
Terminal recommended via Beovision: Beo4
Tuner range VHF, S, Hyper, UHF
UHF (4589)
CTV system B/G PAL
PAL I (4589)
B/C/PAL/SECAM (4585)
TV programmes 59
Stereo decoder NICAM + A2
Recording system HQ
Slow motion 1/7 normal speed
Still picture Noiseless
Tape counter Track, time left, time used

Timer programming
8, 1 year
Sound system Hi-Fi stereo
Video playing time, E-240 SP 4 hours, LP 8 hours
Audio playing time, E-240 LP 8 hours

Power consumption / Minimum
34 watts/10 watts

Cassette format
VHS

Picture functions:
Playback tapes recorded in NTSC 4.43 MHz or PAL 60 Hz
Fast forward and rewind Less than 5 min. E-240
Search forward SP 7 x and 15 x normal speed
Search backward SP 2 x and 7 x normal speed
Search forward LP 5 x and 13 x normal speed
Search backward SP 2 x and 5 x normal speed
Tape heads 5 video, 2 Hi-Fi audio

Connections: AV AV Link 21-pin socket
Camcorder IN 3 phono sockets
RF IN 75 ohms
RF OUT 75 ohms
Camera pause Jack 2.5 mm socket

Downloads

    Type

Language

Type

Date

    Type

Setup Guide

EN

4581, 4583, 4586, 4587, 4589

11-92

BeoCord VX7000 Setup Guide

User Guide

DK

4581, 4583, 4586, 4587, 4589

11-92

BeoCord VX7000 User Guide

User Guide

EN

4581, 4583, 4586, 4587, 4589

11-92

BeoCord VX7000 User Guide

User Guide

FR

4581, 4583, 4586, 4587, 4589

11-92

BeoCord VX7000 User Guide

User Guide

DE

4581, 4583, 4586, 4587, 4589

11-92

BeoCord VX7000 User Guide

User Guide

NL

4581, 4583, 4586, 4587, 4589

11-92

BeoCord VX7000 User Guide

Service Manual

Multi

4581, 4583, 4586, 4587, 4589

11-92

BeoCord VX7000 Service Manual

Frequently Asked Questions

No FAQs available.
