Captivating no matter where you place it, this powerful home speaker sounds as beautiful as it looks.
Beosound 2 has a built-in proximity sensor that makes the control panel light up when your hand is hovering over the controls. The top of the speaker works as a minimalistic control panel. Simply tap one of the four favourite buttons to start one of your preferred radio stations or playlists, turn the wheel to adjust the volume and tap on one of the arrows to change tracks.
Beosound 2 works out where it is in the room to give you perfect playback, every time. Ensuring bass, mids and highs are never too overpowering or weak. Wherever you place it, it gives a standout performance. No muddiness. No fuzziness. Just pure, clean sound. As the artist intended.
Crafted in high-grade aluminium with incredible attention to detail. But our material choice go well beyond aesthetics. It also provides superior acoustic properties thanks to its material stiffness and seamless surfaces that eliminate any distortion of your sound.
10-60 m² 100-600 ft²
1 x ¾” tweeter 2 x 2″ mid-range 1 x 5 ¼” woofer
1 x 15 W class D for tweeter 2 x 15 W class D for mid-range 2 x 30 W class D for woofer
Total: 105 W
33 – 23.400 Hz.
94 dB SPL
84 dB SPL
Pair two Beosound 2 3rd Gen to enjoy a stereo listening experience.
Active Room Compensation Acoustic Lens Technology Adaptive Bass Linearization Thermal Protection
Presets available and fully customisable through the Bang & Olufsen App
David Lewis Designer – Torsten Valeur
Aluminium Polymer
20 W x 43.1 H x 20 D cm
4.1 kg
Typical 15 W Standby: 4,5 W
Power supply built-in Power cable
Bluetooth 5.3
Android: SBC iOS: SBC, AAC
Dual-Band Wi-Fi (2.4 & 5 GHz) IEEE 802.11 b/g/a/n/ac/ax
Apple AirPlay Spotify Connect Google Cast TIDAL Connect B&O Radio Deezer QPlay 2.0
Yes
1 x Ethernet 1 x Line-in via USB-C 1 x Power
Bang & Olufsen App Beoremote One BT Beoremote Halo
Yes
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
” BeoSound 3000: the design may be a Bang & Olufsen classic, but BeoSound 3000 and BeoSound Ouverture refuse to rest on their laurels. Access to new musical sources and fresh loudspeaker options ensure that the concept remains an open invitation to make something special out of your music.
With BeoSound 3000 everything is upright and out in the open so that you can see how it works and understand how it reacts when you press its buttons. Even the simple act of placing a CD has been made part of the overall experience and enjoyment. It combines radio with an advanced CD player, and – as something new – lets you access your digital music files directly from your own PC. As well as offering radio and CD, the BeoSound Ouverture also has an intelligent tape function ” (B&O catalogue 2001 – 2002)
Both products can be put together with any BeoLab loudspeaker – which gives you the option of an impressive set up on matching stands with two BeoLab 4000 speakers, or a more compact solution between newly redesigned BeoLab 2500 speakers.
With a design that’s undoubtedly becoming a Bang & Olufsen classic, BeoSound 3000 and BeoSound Ouverture are an open invitation to make something special out of your music. BeoSound 3000 is the former Beocenter 2300 (first introduced in 199) but with a whole host of new electronics, features and look including a larger metal CD ‘cover’ and N.MUSIC. The new styling was released to the UK market in September, 2001.
With BeoSound 3000, everything is upright and out in the open, so that you can see how it works and understand how it reacts when you press its buttons. Even the simple act of placing a CD has been made a part of the overall experience and enjoyment.
It combines radio with an intelligent CD player that can name your favourite 200 discs, store your own preferred track sequences for them or skip unwanted ones permanently. With the latest Beolink® PC2 software application, you can also access your digital music collection directly from the BeoSound 3000.
Bring new life to old CDs by changing their track sequence with the Random Play function. Or program it to skip over any unwanted tracks and to play the ones you want, in the order you prefer. Name your favourite 200 CDs and store your own track preferences for them in the extended memory and the BeoSound 3000 will remember it the next time you play one of the CDs. With the CD function of the BeoSound 3000 you’re also able repeat a desired passage of a CD, whether it is within the same track or stretching over a number of tracks.
There’s room for up to 60 pre-set stations on the BeoSound 3000’s intelligent AM/FM radio. You can also name each individual radio station, to give you a complete overview of your radio listening. With the BeoSound 3000 you can wake up to your favourite piece of music. The BeoSound 3000 can be programmed for the entire week and will automatically turn itself off again after playing for any length of time you choose.
Just raise a hand and watch as the glass doors glide silently aside. It’s the BeoSound 3000’s way of saying “welcome” and reveals that a special experience is about to begin. Of course, a simple on/off button would do, but then what would be so special about that? Beocenter 3000’s unassuming rubber key pad hides a contact foil, which, in turn, covers a matrix of vertical and horizontal cords. When a control is pressed, the cords connect and the microprocessor is activated.
It’s a dream come true – a music system that can fill your life with music without filling your home with equipment. The flat upright design of BeoSound 3000 means that it’s slim enough to sit by itself upon the narrowest shelf or light enough to be hung directly on a wall with any pair of loudspeakers in the BeoLab range.
It used to be that your music system was placed in one room in your home and you had to go there to listen to it. Not anymore. With Beolink®, you can place extra loudspeakers in any room in the house and access the musical options of your BeoSound 3000. The BeoSound 3000 is also equally at home in a Surround Sound setup and will give you an unmatched sound experience.
There’s so much good music on the Internet, but until now you had to be in the same room as your computer to enjoy it. Not anymore. With the latest Beolink® PC2 software application, you can access your digital music collection directly from the BeoSound 3000 in the living room – and send it from there to any other room in the house via the Beolink system.
The glass doors on the BeoSound 3000 and BeoSound Ouverture are opened and closed by steel wires driven by an electric motor via a gearbox. The motor is triggered by an infrared system that detects your approach.
This classic design was reincarnated over a 21 year period with various mounts and stands. Floor stands were available with a pole stand or CD and tape storage, wall mount solutions allowed for the Hi-Fi only, or with BeoLab2500 speakers until these were discontinued
Dimension W x H x D / Weight:
32 x 36 x 16 cm / 7 kg
Cabinet finish: Black/aluminium
Power consumption: Typical 23 watts/standby < 3 watts
Tuner: Built-in
Pre-tuned radio programmes: 60 FM or AM
Radio ranges: FM-LW-MW
RDS: Built-in
Compact disc: Built-in
Disc sizes: 12 cm, 8 cm
Frequency range: 20 – 20,000 Hz, +/- 1 dB
Signal-to-noise-ratio: Typical 101 dB, A, weighted
D/A converting: Bitstream, analogue filtration
Available documents are listed, if none are listed then please reach out to see if we have them.
Type | Language | Type | Type | |
Service Manual | EN | 2671, 2672, 2673, 2674, 2675, 2676, 2677, 2680 | BeoSound 3000 Service Manual |
Please let us know
“BeoSound 3200 lights up in a soft glow of anticipation as soon as you reach out with your hand. Everything is out in the open so that you can see how it works and understand how it reacts”
BeoSound 3200, has a Hard Disk Drive with the capacity to store up to 396 compact discs. The CDs are stored in four groups of 99 and each group can be edited and named, in order to facilitate the easy location of your music. All other main functions are as the existing BeoSound 3000.
” Technology may be the foundation of the experience, but it should never get in the way of the senses. It’s the simple understanding that has created the concept behind BeoSound 3200.” It integrates a unique CD memory function that can store up to 396 of your favourite CDs in four individual groups. For simple and effective operation, each group is designated a colour that matches both the coloured buttons on the control panel and those on the optional Beo4 remote control you can choose to store an entire CD or just your favourite tracks and each entry can be named for easier recognition. Groups can be arranged according to type or be designated to different members of the family.
While the technology behind BeoSound 3200 is new, it retains a characteristic Bang & Olufsen personal feel. The glass doors slide open at a wave in an invitation to be used . Everything is upright and in the open, functions are clearly displayed and easy to understand. Even the simple act of placing a CD has been made part of the overall enjoyment.
BeoSound 3200 may be placed on a wall, positioned on a shelf or on the floor on a floor stand. When placed on a self or table, the system has a natural 13 degree slant for easier viewing and control. It may be used with any BeoLab loudspeaker enabling a number of impressive setup possibilities. It could be place between a pair of BeoLab 2500 active loudspeakers for example, or on matching stands with BeoLab 4000.
BeoSound 3200 is an audio system embracing CD, radio, CD memory and digital music files via Beolink®. It comes in one colour – aluminium and black – and can be positioned in different ways.
Digital Jukebox
The new BeoSound 3200 sees Bang & Olufsen introduce new technology that allows storage of almost 400 CDs – giving you the chance to create their very own digital jukebox.
Bang & Olufsen is bringing out a new system that allows you to record a CD as it plays. This gives the BeoSound 3200 the capacity to reproduce ‘first play’ quality of over 4,000 tracks. By creating technology that memorises almost 400 CD compilations, Bang & Olufsen is revolutionising the way we use and store CDs.
Music Selection
The technology is such that you will be able to select the tracks to be recorded, freeing up memory for the favourites only. The system will also allow you to file the CDs into 4 different personalised categories, be it Jazz, Classical, Dance or Hip Hop, allowing you to match the music to the moment at a touch of a button.
Other functions
The signature Bang & Olufsen craftsmanship is naturally seen in the new system. As your hand approaches, the smoked glass doors opens without a touch. The system boasts 60 radio station presets and a facility to function as a Beolink® master, distributing music to any Bang & Olufsen speaker in the house. Furthermore, if you wish to connect the BeoSound 3200 to a PC, the Beolink® PC2 connection facilities allow access to MP3 and WMA music files stored on the PC hard drive.
Active speakers
Choose any of the active loudspeakers from Bang & Olufsen’s BeoLab range for an experience that’s as pleasing to the eye as it is to the ear. Tall and elegant, the BeoLab 1 speakers deliver 300 watts of Bang & Olufsen ICE power digital amplifier driven bass. The appealing BeoLab 8000, slim BeoLab 6000 or placement friendly BeoLab 4000 speakers may be utilised as well. The recently redesigned BeoLab 2500 speakers easily allow you to opt for today’s spin on the original design expression.
A mountain of music – Built in CD memory in BeoSound 3200 allows storage of almost 400 CD
A vast amount of storage space, hidden within Bang & Olufsen’s BeoSound 3200, present a plethora of musical experiences this season. Operation is straightforward and simple, whether storing your own CD or playing one back from the CD memory. Compressed to allow more storage without sacrificing audible quality, a mountain of music is contained in the already sleek lines of this design classic.
“In 1991 Bang & Olufsen broke new ground with the introduction of the Beosystem 2500 concept – the first hi-fi system to stand tall amongst the flat contemporary rack systems of its day. We renew this classic product family with incorporation of a CD memory into its newest member, the BeoSound 3200”, states President and CEO Torben Ballegaard Sørensen, who continues,
“We’ll utilise the CD memory to offer our customers new benefits and convenience when enjoying their music collection. All your music, or at least a big part of it, waits for you at the touch of only one button”.
Just load a CD, decide in which one of the four possible groups you want to keep it, and press “Copy” on the hands-on operation panel. Storage of the entire CD begins! Don’t like all the tracks on your CD as much as the others? Don’t fret, because BeoSound 3200 gives you the opportunity to copy only the ones you yourself choose. You can always add them later, should your tastes change.
Whilst every one of your CDs contains inaudible information regarding the publisher, artist, batch production number and more, for you, they’re only about the music. Store the names of 200 physical CD’s in addition to the names of the almost 400 CDs already found on the 40 gigabyte hard disk. So sit back and experience “Romance” in the pleasing built-in display, rather than “Disk 1, track 5”.
Four 99-CD capacity groups are accessed by the coloured keys on the front of BeoSound 4300 or via the Beo4 remote control. Name them yourself, just as you wish: Rock, Pop, Jazz and Classics, or why not Dad, Mum, Brother and Sister? Enjoy music in your groups.
Your hand approaches, and the smoked glass doors open magically. Wishing you welcome into a world of musical experiences, the door movement is designed to be smooth with a slow start, acceleration and a gentle stop when the door is at its final position. A magical experience provided by combing some infrared light, a bit of gearing, a length of steel wire and Bang & Olufsen ingenuity.
Advanced CD memory functions are but one element in the entire BeoSound 3200 experience. Found between the high-gloss anodised aluminium clamper lid, the built-in CD-player accommodates both 12 and 8 cm discs. With 60 radio station presets, the AM/FM radio won’t leave your air-borne audio entertainment wishes behind either distributing music to any Bang & Olufsen speakers around the home in wish to connect your BeoSound 3200 to a PC, the Beolink® PC2 connection facilitates access to MP3 and WMA music files stored on your PC hard disk.
Choose any of the active loudspeakers from Bang & Olufsen’s BeoLab range for an experience that’s as pleasing to the eye as it is to the ear. Tall and elegant, the BeoLab 1 speakers deliver 300 watts of Bang & Olufsen ICEPower digital amplifier driven bass. The appealing BeoLab 8000, slim BeoLab 6000 or placement friendly BeoLab 4000 speakers may be utilised as well. The recently redesigned BeoLab 2500 speakers easily allow you to opt for today’s spin on the original design expression
This classic design was reincarnated over a 21 year period with various mounts and stands. Floor stands were available with a pole stand or CD and tape storage, wall mount solutions allowed for the Hi-Fi only, or with BeoLab2500 speakers until these were discontinued
32 x 36 x 16 cm / 7 kg
Cabinet finish: Black/aluminium
Power consumption: Typical 22 watts/standby < 3 watts
Tuner: Built-in
Pre-tuned radio programmes: 60 FM or AM
Radio ranges: FM-AM
RDS/Naming: Built-in
Compact disc: Built-in
Disc sizes: 12cm, 8cm
Frequency range: 20 – 20,000 Hz, +/- 1 dB
Signal-to-noise-ratio: Typical 101 dB, A-weighted
D/A converting: Bitstream, Analogue filtering
Features:
Programming
Edit
Random
Repeat
CD Memory:
Features:
– Built-in Hard disc drive
– Random
– Naming
– Compact disc grouping. 4 groups
Capacity: Max 99 discs in each group
A/D, D/A converter: Sigma-delta Bitstream
Frequency range: 20 – 20,000 Hz, +/- 1 dB
Signal-noise ratio: > 100dB
Audio processing: Compressed audio
Bitrate: MP3 at 192 KB
Connections:
Power Link (two)
AUX
FM aerial, 75 ohm
AM aerial (Dedicated)
Master Link (ML)
Headphone/Mini-Jack
Beolink®: Master Link (ML)
Accessories:
Remote control: Beo4
Wall bracket system: 2087 Black
Wall bracket, center: 2052 Black
Stand 2051: Aluminium, Black, Blue, Green, Red
Floor center stand: 2068 Aluminium
Available documents are listed, if none are listed then please reach out to see if we have them.
Type | Language | Type | |
User Guide | EN | BeoSound 3200 | |
Service Manual | EN | BeoSound 3200 | |
Service Manual | EN | BeoSound 3200 Service Manual - From serial no. 19533053 |
Please let us know
Beosound Theatre doesn’t just lead from the front. Twelve custom drivers direct sound above, below and to the sides of your screen, creating a room-filling soundscape that immerses you in the moment. Dolby Atmos allows for true surround sound experiences, and a coaxial centre channel ensures crisp and clear speech. You won’t miss a word or whisper.
Unfolding sound
BeoVison Avant is a celebration of movement.
An unforgettable fusion of Ultra High-Definition (4K) picture and iconic Bang & Olufsen sound, that unfolds before your very eyes.
Redefining TV sound
Precision tuned to Bang & Olufsen’s most exacting standard, BeoVision Avant redefines the audio impact a TV can deliver. The 3-channel speaker system harnesses three dedicated tweeters, three midrange units and
two powerful bass drivers. The result is a fusion of clarity and power that truly embodies Bang & Olufsen’s commitment to ultimate sound.
Contrasted imagery
BeoVision Avant combines local dimming across more than 8 million pixels, bringing out the tiniest details in the action. Experience the most extreme sports or action footage with crystal sharp, dynamic precision.
Please let us know
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
The long awaited Digital Music player from B&O strikes out in a new direction for the Danish Company. Revolutionary control surfaces mean that the days or smudged touch screens are a thing of the past, yet the controls maintain a real sense of interaction with the music.
This is what makes the Beosound 5 special. Unlike other products on the market, this actually compares the actual music using a complicated algorithm to make an never ending musical play list completely automatically. You can construct your own list but MOTS will still, if you wish continue this on once your choices have reached the end.
The Beosound 5 is partnered with the new Beomaster 5. This is an updated Beomedia and has a storage capacity of 500Gb. All Beosound 5s will come with the Beomaster 5 and it is also possible to have the Beomaster 5 built into a Beovision 9. Up to 28,000 tracks at WMA Lossless quality can be stored on the disc which should mean enough music to play a new track without repeating itself for 75 days.
Later versions had the more reliable 1Tb HDD fitted which could store double the amount of music!
The head unit is supplied with a flat to wall bracket in the box. Optional mounts extended (angled) wall mount, table mount and floor mount were all available from launch. A wall mount bracket for the connection box was launched with BeoSound 5
DIMENSIONS/WEIGHT 12” x 7” x 3” / 5.8 lbs(31cm x 19cm x 8cm/2.65 kg)
DISPLAY 10.4”—1024 x 768
CONNECTIONS Only connects to BeoMaster 5 (DVI, power, USB)
POWER CONSUMPTION Power supplied via BeoMaster 5
FEATURES N.Music, N.Radio, MOTS (More Of The Same)
ACCESSORIES Wall bracket (included); Aluminum/black
Wall bracket extended; Aluminum/black
Table stand: Iron/black
Floor stand: Iron/aluminum
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
Encore would seem an apt name for this product at first glance, as it would appear to be a BeoSound 5. However this disguises the fact that B&O has moved to a platform that can support many types of third party storage and is also introducing a new concept in connectivity.
Please let us know
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
The new addition the B&O MP3 range, the Beosound 6 strikes out in a different direction for the company and embraces the prevailing trend for flash memory and a colour screen. Planned for launch in the summer, the Beosound 6 will come with a leather case and A8 earphones.
Unlike the Beosound 2, the Beosound 6 does not use SD cards but relies on an internal memory of 4Gb. This is addressed through a port at the base which attaches to the USB port on the computer.
It would appear that the Beosound 6 is based upon the Samsung YP-Z5 MP3 player and shares that players control interface. This moves away from the accustomed Beo4 type control and, if the Samsung is anything to go by, is not as user friendly.
The Beosound 6 could be seen as a me too type device and with little of the usual B&O flair, but B&O are clearly aiming at those people in the Apple iPod Nano market who want something a little different. The screen interface would seem to have been modified gently to resemble the B&O style. One would hope that the sound quality would be of the same standard as the Beosound 2 and the provision of the A8 earphones can only help this.
DIMENSIONS (WXHXD) / WEIGHT 90.7 x 42.7 x 12.2 mm / 65 g
FINISH Polished stainless steel/soft-touch lacquered plastic
MEMORY 4Gbyte
DISPLAY 1.81 Inch TFT LCD 128 x 160 pixels
SUPPORTED AUDIO FORMATS MP3, WMA, OGG
OPERATING SYSTEM PC Windows XP SP2
MAC iTunes: BeoSound 6 plug-in needed
INTERFACE USB 1.1. (USB 2.0 high speed support)
BATTERY Built-in, rechargeable, approx. 40 hours playing time
MAINS VOLTAGE 100 – 240 V AC
CONNECTIONS Earphones, USB and mains adaptor via 18 pin connector
INCLUDED ACCESSORIES Bang & Olufsen Earphones, USB-cable, travel charger and leather bag
Available documents are listed, if none are listed then please reach out to see if we have them.
Please let us know
A late entry into the market but maybe the best sounding, the Beosound 8 benefits from the active speaker technology that B&O has championed for many years. Class D amplification is used for the two way loudspeakers and a placement switch is present which allows free standing, wall or corner settings.
The dock connection allows iPods, iPhones or iPads to be used and the provision of a line in connection allows other devices to attach.
In addition, a mini USB socket allows the customer to connect either a PC or Mac or an Airport Express to allow music to be played from their computer. A special Application written for the iPhone will be available which allows the music library to be browsed and also gives the BeoSound 8 both Alarm Clock functions and Net radio capabilities.
A wall bracket is available or the Beosound 8 can be used as a table top set.
Initially the speaker covers will be either black or white but Blue. Purple , Green and yellow covers will soon be available.
Control will either be via the iPod or with the Beosound 8 remote, which is aluminium. The set is also controllable with the Beo4,5 or 6.
The BeoSound 8 came in two ‘generations’ – the first being the regular BeoSound 8 with the old iPhone 20-pin connector, then the BeoPlay A8 (the ‘A’ standing for ‘Airplay’) which had no connector, but you could add a simple push-fit ‘Apple Lightning Connector’ for later Apple products if required.
DIMENSION
W x H x D/ WEIGHT 66.1 x 23.9 x 16.4 cm/4.25 kg
MATERIAL(S) Painted plastic, Aluminium and Fabric
COLOUR(S) Aluminium/white with white fabric frame
Aluminium/black with black fabric frame
POWER CONSUMPTION Typical: 10 W; Standby: 0.4 W
LOUDSPEAKER(S)
CABINET PRINCIPLE Sealed box
EFFECTIVE FREQUENCY RANGE* 38.3 – 24,000 Hz
CONNECTIONS iPod/iPhone/iPad connector, USB
Line-in via Phono
ACCESSORIES BeoSound 8 remote control (included)
Table stand/feets (included)
Wall bracket (included)
Fabric frames:
Yellow, purple, green, blue, black and white
*EFFECTIVE FREQUENCY RANGE is measured at -10 dB re. Ref level (200-2000 Hz)
Available documents are listed, if none are listed then please reach out to see if we have them.
Type | Language | Type | Date | Type | |
User Guide | Multi | 2905, 2906 | 10-11 | BeoSound 8 User Guide | |
Service Manual | EN | 2905, 2906 | 10-11 | BeoSound 8 Service Manual |
Please let us know
BeoSound 9000 makes a strong statement with your music – but leaves it up to you to decide exactly how.
Music may not be essential to life, but it’s hard to live without it. That’s why BeoSound 9000 makes such a big thing about bringing your music out into the open and letting you create your own personal jukebox with the music that means the most to you. Combine BeoSound 9000 with the latest Beolink® PC 2 software application and you can access the digital music files on your computer’s hard disc. Place it upright in a bookcase, lay it flat on a shelf, or hang it directly on the wall – either vertically or horizontally. It can stand between a pair of BeoLab 1 or BeoLab 8000 loudspeakers, or with any other speaker in the BeoLab range. With BeoSound 9000, the possibilities – and the enjoyment – are endless ” (B&O Catalogue 2001 – 2002)
BeoSound 9000 represents the latest technology from Bang & Olufsen today. The 6-CD changer is the fastest in the world. If allowed to continue its momentum it would travel 100km/h in just 5,5 seconds… faster than a Ferrari from a stop position! It can be positioned in several different ways and the display text automatically adjusts itself to be readable. The unit too features a FM/AM tuner with RDS and is equipped with the new MasterLink connections and can be connected directly to the Beovision Avant and AV9000.
The discs are easily loaded and held by spring suspended jaws. Discs not in play can be replaced without interrupting the playback. The auto-positioning feature ensures that CDs are always returned to the position in which they were first placed. With the CDs visible and positioned correctly, there is easy access to the text information printed on the label. The glass-covered natural aluminium plate holds the CDs and the rails for the CD carriage, while a backlit acrylic plate illuminates the CD currently playing.
BeoSound 9000 offers unprecedented flexibility for a product of this type, and to ensure the same uniform movement of the glass cover regardless of the placement of BeoSound 9000 vertically or horizontally, upright or flat. To counteract the effect of gravity, a digital time control constantly monitors the movement of the cover and adjusts the motor, keeping the complete movement within 3.5 and 4 seconds.
Such an abundance of fast moving mechanics means that special measures have been taken to ensure that BeoSound 9000 is safe to operate. Small prismatic lenses are placed at each end of the aluminium frame, controlling an infrared beam across the front of BeoSound 9000. If the beam is violated, the CD clamper will stop immediately.
If the glass door is lifted while the clamper is in motion, it will decelerate immediately. A power failure feature ensures that the clamper is not damaged in a gravitational free-fall, if BeoSound 9000 is mounted vertically.
Ingenious engineering solutions and intricate mechanical movements in a product that continues to surprise and delight users today – and all this from the inspiration of old vinyl records spinning on the record player’s turntable.
The unit may be played in one of seven different positions. In each one, gravity has a different effect on the CD clamper (the aluminium ‘arm’ which rests over each CD when it is being read), yet it still works with the same precision and speed: a good example of how Bang & Olufsen uses technology to overcome acceptable limitations. Place BeoSound 9000 upright in a bookcase, lay it flat on a shelf or hang it directly on the wall – either vertically or horizontally. It can stand, for example, between a pair of BeoLab 1 or BeoLab 8000 loudspeakers (as above), or with any other speaker in the BeoLab range. With BeoSound 9000, the possibilities – and the enjoyment – are endless!
BeoSound 9000 starts with the technical excellence of the CD, but moves on from its limitations. A couple of good old-fashioned mechanical virtues make a welcome comeback. You can see it work and understand how it reacts when you touch its buttons. Or you can sit back with your Beo4 remote control and browse through over 7 hours of musical pleasure.
BeoSound 9000 makes a virtue of displaying the features that so many manufacturers try to hide away” welcoming the user with open arms to use it.
BeoSound 9000 works so fast and so quietly that the change-over between two CDs seems no longer than the normal interval between tracks. Using the inaudible initial lead information on the discs, each CD can be named and memorised, and will be left in the same position as it was loaded, with its title clearly legible. Enter up to 200 titles in the memory and they’ll appear on the display whenever one of those CDs is played.
The FM/AM radio has memory for up to 60 stations which can be identified by their names instead of their frequency numbers. Set the timer and wake up to your favourite programmed CD sequence or radio station.
Lift the lid on BeoSound 9000 and the extensive control panel with timer, editing and sound adjustment operations is at hand. Since the BeoSound 9000 can be placed in a great number of positions, the control panel can turn as you prefer. The display follows the same orientation, of course!
Auto-positioning was one of the challenges that Bang & Olufsen’s engineers had to meet because of BeoSound 9000’s clear versatility in placement. Using the inaudible initial lead information present on most compact discs, the BeoSound 9000 is able to detect and memorise a desired position for the CD.
When it’s time to stop the CD, a servo system decreases the speed of rotation, the position mark is detected, and this effects the final braking and halt. A servo calculates the braking length for the CD, processes and stores the information. So the next time the CD will stop even faster, because BeoSound 9000 now knows where and when to apply the brakes. A total of 360 perforations ensure that your CD will stop precisely at the point at which you placed it in the rack.
The secret behind the precision of the movable clamper lies in two sensors which monitor its exact position and speed more than 60 times a second, and in its digitally-controlled motor, which compensates for even the slightest variation in movement.
Note: For owners of BeoSound 9000 who wish to use BeoLab 5 with this particular CD player, another feature of these new active speakers will be a direct digital feed from the optical output of BeoSound 9000 – the output not used at present!
Since the early days of the gramophone, record changers have been known and appreciated for their long playing time. The modern version of the record – the CD – adds a new perspective to the old old idea.
In designing BeoSound 9000 from scratch, a number of design models were created in order to illustrate various ideas.
The ‘library machine’ was one of them. It could hold an entire CD collection ready for playback. However the stored discs disappeared out of sight into the innards of the machine. This was seen as a problem because compact discs are not able to give a readout of a library’s contents, making an automatic catalogue display impossible, and since the design group felt a primary manual entry of all CD data was out of the question, the idea was quickly abandoned.
In returning to square one, the dominating feature – as in a CD changer – is the ability to play continuously for a long period of time. In coming up with a solution for this problem, together with presenting visual feedback, the discs were placed with their covers upwards and in a line next to each other, protected, under a lid of transparent glass. This was the main idea behind the very first design model of BeoSound 9000.
However, David Lewis, as Bang & Olufsen’s chief designer presented the first design model of BeoSound 9000 in two editions: the one which we know today with its 6 CDs, as well as another model comprising ten compact discs laid out in a line next to each other (see picture above).
The design group liked the 10-CD edition; it looked stunning, but in use it was limited to just once placement (unlike the eight different placements that the currently-produced BeoSound 9000 offers). The 10—CD version was subsequently shelved with the 6-CD version going into production in 1996.
David Lewis’ BeoSound 9000 from 1996 makes a virtue of showing its function. It clearly displays, by the 6-CD slots, that its function is the playing of music It can be placed horizontally on a wall or vertically on a special column when it becomes almost a sculpture for the home. Like B&O’s other products BeoSound 9000 contains the most advanced techniques around but shies away from technical mystique with its interface being simple and self-explanatory.
Lift the lid on BeoSound 9000 and the extensive control panel with timer, editing and sound adjustment operations is at hand. Since the BeoSound 9000 can be placed in a great number of positions, the control panel can turn as you prefer. The display follows the same orientation, of course. BeoSound 9000 may also be controlled by the optional Beo4 remote control.
On the optional bracket, the BeoSound 9000 displays itself raised at an angle, or standing tall. Attach it horizontally and watch all the CDs stop in exactly the same positions as they were loaded in. Or you might opt for the floor stand as a bold musical statement. Hang BeoSound 9000 vertically on the wall and see how the display automatically changes orientation if you reverse the control panel.
Combine BeoSound 9000 with the latest Beolink® PC2 software application and you can access the digital music files on your computer’s hard disc directly from your music system in the living room. And if BeoSound 9000 is part of a Beolink® setup, you can enjoy your virtual music collection in any room in the house.
Six CDs presented neatly in a row, with all the titles legible. After playback, BeoSound 9000 simply stops its CDs in exactly the position in which they were first loaded.
Auto-positioning was one of the challenges that Bang & Olufsen’s engineers had to meet because of BeoSound 9000’s clear versatility in placement. Using the inaudible initial lead information present on most compact discs, the BeoSound 9000 is able to detect and memorise a desired position for the CD.
When it’s time to stop the CD, a servo system decreases the speed of rotation, the position mark is detected and this effects the final braking and halt. A servo calculates the braking length for the CD, processes and stores the information. So the next time the CD will stop even faster, because BeoSound 9000 now knows where and when to apply the brakes. 360 perforations ensure that your CD will stop within just 1° of the position in which you put it on!
BeoSound 9000’s CD reader is propelled back and forth by a powerful motor. An optical system allows a microprocessor to monitor the reader’s movement between the six CD stations. The total distance of 63 cm is divided into 1,040 separate positions so that the reader can be positioned to an accuracy of just 0.6mm. Given that the reader accelerates from 0 to 100km/h in just over five seconds, it’s vital that the electronic and mechanical components are in perfect harmony. BeoSound 9000 is one of Bang & Olufsen’s most compact products, housing no fewer than 2,910 different components.
Bang & Olufsen boasted 6 mounting positions for BeoSound 9000 from the range of stands and brackets launched with this super flexible icon. The table stand and floor stand were complimented with a pair of wall brackets giving the choice of horizontal or vertical mounting
BeoSound 9000: 6 CD stations • extended programming • memory for up to 200 titles • FM/AM radio with 60 presets • optional Beo4 remote control operation • connections for Beolink® and headphones • wall bracket and floor stands are optional
Dimension W x H x D / Weight:
30 x 90 x 7 cm / 11.5 kg
Cabinet finish: Black/aluminium
Power consumption: Typical 12 W, standby < 1.2 W
Tuner: Built-in
Pre-tuned radio programmes: 60 FM or AM
Radio ranges: According to type
RDS: Yes
Compact disc: Built-in
Disc sizes: 6 x 12 cm, 8 cm
Frequency range: 20 – 20,000 Hz, +-1 dB
Signal-to-noise-ratio: Typical 101 dB, A weighted
D/A converting: Bitstream, analogue filtration
Features:
Programming
Random
Repeat
Naming (200 titles)
Edit
Connections:
Power Link (two)
AUX
FM aerial, 75 ohm
AM aerial (Dedicated)
Master Link (ML)
Headphone/Mini jack
Digital output (S/PDIF = Sony/Philips Digital Interface)
Beolink®: Master Link (ML)
Remote control: Beo4
Accessories:
Bracket
Wall bracket, horizontal
Cable cover
Vertical wall bracket
Stand, adjustable in two heights
Available documents are listed, if none are listed then please reach out to see if we have them.
Type | Language | Type | Type | |
Reference Guide | EN | BeoSound 9000 Reference Guide | ||
User Manual | EN | BeoSound 9000 User Manual | ||
Circuit Description | EN | BeoSound 9000 Circuit Description | ||
Service Manual Preliminary | EN | 2521, 2522, 2523, 2524, 2525 2526, 2527, 2528, 2529, 2530 | BeoSound 9000 Service Manual Preliminary | |
Service Manual | EN | 2521, 2522, 2523, 2524, 2525 2526, 2527, 2528, 2529, 2530 | BeoSound 9000 Service Manual | |
Service Manual | EN | 2561, 2562, 2563, 2564, 2565, 2566, 2567 | BeoSound 9000 Service Manual | |
Service Manual | EN | 2571, 2572, 2573, 2574, 2575, 2576, 2577, 2580 | BeoSound 9000 Service Manual |
Information valid for:
Power failure precautions; safety and precautions
BeoSound 9000 Mk I II & III working with BeoLink PC 2, BeoPort or BeoMedia 1 is another hot topic which needs to be cleared up. So, here is the information you need!
Like many Audio Visual ‘urban myths’ (such as Plasma Screens needing re-gassing after 5 years), earlier versions of the BeoSound 9000’s ability to work with N.MUSIC has made everybody somewhat confused after many ‘yes it can’, ‘no it can’t’, ‘my dealer told me’ statements and contradictions.
It’s not that anybody is deliberately giving out incorrect information, but more that those who have access to the definitive information don’t always read it for themselves, they simply repeat what they’ve heard – resulting in the start of an urban myth.
So, the definitive answer is that all BeoSound 9000’s can be upgraded to support N.MUSIC and here are the details:
BeoSound 9000 type 252x produced from April ’96 (MkI) and Beosound 9000 type 256x (MkII) produced from September ’98 simply require a software update. It is a chip change, and although the software level may change from time to time the part number remains the same – which is 8344087. Quote this to your dealer if they are unsure.
BeoSound 9000 type 257x (MkIII) produced from June ’01 was released fully compatible and therefore no need for any upgrades.
Now, for the commands on your Beo4.
From software 4.2, N.MUSIC was available via the list key (you need to add it first, see Beo 4 user guide for details – available as a download from BeoWorld if you do not have one).
If you find that N.MUSIC, N.RADIO are not available to add to your list key all is not lost, selecting A.TAPE 2 will activate N.MUSIC and PHONO will give you N.RADIO
The circuit controlling the movement of the CD carriage has a built-in safety function which protects your fingers, etc. from being hit by the fast moving carriage.
This circuit depends on light/reflections, and works via opto-coupling devices built into the two small ‘pegs’ . When the glass door is opened, or if something interrupts the light circuit, the carriage slows down in speed, and finally comes to a halt. Over time dust may build up and thus reduce the light emitted to and from the opto-coupling devices.
Dust particles on the inside of the glass door may also cause extraordinary reflections which may be interpreted by the safety function in a wrong way. So, in order to prevent malfunction of the safety circuit, we recommend that you wipe dust off the two pegs on a regular basis. Likewise, when cleaning the surfaces of the BeoSound 9000, remember also to clean the inner surface of the glass door.
